Plain Annealed Aluminum Class 1 to BS EN 60228
PVC Type TI4 to BS EN 50363-3
PVC Type 10 to BS 7655-4.2
-20°C
70°C
1
Black
For current ratings refer to IEC Strandard
Nominal cross sectional area mm² | Approx. overall dia. mm | Approx. Dia. Under Armour mm | Nominal dia. of armour wires mm | Approx. cable weight kg/km | Max. conductor resistance @ 20°C Ohms/km | Conductor short circuit rating (1 sec) kA | Armour short circuit rating (1sec) kA/th> | Direct in ground Amps | In duct Amps | In air Amps | Volt drop single phase AC touching mV/A/m |
---|---|---|---|---|---|---|---|---|---|---|---|
BS5467 4 Core Cables |
|||||||||||
1.5 |
12.9 |
8.3 |
0.9 |
400 |
12.1 |
0.20 |
0.78 |
32 |
26 |
26 |
27 |
2.5 |
14.4 |
9.8 |
0.9 |
470 |
7.41 |
0.35 |
0.92 |
42 |
34 |
35 |
16 |
4 |
15.7 |
11.1 |
0.9 |
580 |
4.61 |
0.57 |
1.0 |
55 |
45 |
47 |
10 |
6 |
17.9 |
12.4 |
1.25 |
810 |
3.08 |
0.86 |
1.6 |
69 |
56 |
59 |
6.8 |
10 |
19.7 |
14.2 |
1.25 |
10875 |
1.83 |
1.4 |
1.9 |
92 |
75 |
82 |
4 |
16 |
22.4 |
16.7 |
1.25 |
1450 |
1.15 |
2.2 |
2.2 |
119 |
96 |
107 |
2.5 |
25 |
27.3 |
20.7 |
1.6 |
2060 |
0.727 |
3.6 |
3.2 |
152 |
124 |
140 |
1.65 |
35 |
30.2 |
23.4 |
1.6 |
2550 |
0.524 |
5.0 |
3.7 |
182 |
149 |
172 |
1.15 |
50* |
32.2 |
26 |
1.6 |
2875 |
0.387 |
7.1 |
4.1 |
217 |
177 |
209 |
0.87 |
70* |
38 |
30.6 |
2 |
4250 |
0.268 |
10.0 |
6.1 |
266 |
218 |
263 |
0.6 |
95* |
41.7 |
34.1 |
2 |
5475 |
0.193 |
13.6 |
6.8 |
319 |
263 |
324 |
0.45 |
120* |
45.4 |
37.6 |
2.5 |
7175 |
0.153 |
17.2 |
9.5 |
363 |
300 |
376 |
0.37 |
150* |
50.6 |
41.6 |
2.5 |
8475 |
0.124 |
21.4 |
10.6 |
406 |
338 |
430 |
0.3 |
185* |
55.3 |
46 |
2.5 |
10350 |
0.0991 |
26.5 |
11.8 |
458 |
382 |
495 |
0.26 |
240* |
61.2 |
51.7 |
2.5 |
13000 |
0.0754 |
34.3 |
13.4 |
529 |
442 |
584 |
0.21 |
300* |
66.8 |
56.9 |
2.5 |
15750 |
0.0601 |
42.9 |
14.8 |
592 |
496 |
666 |
0.185 |
400* |
75.4 |
64 |
3.15 |
20400 |
0.047 |
57.2 |
20.9 |
667 |
570 |
766 |
0.165 |
