Welding Cable Prices

  • Conductor: Copper
  • Insulation: Rubber
  • Insulation Color: Red,Black
  • Temperature Range: -30°C to +90°C
  • Nominal Voltage: 450/750V
  • Test Voltage: 1000V
  • Standard:IEC, GB,UL

Welding Cable Prices Specification

  • Conductor

    Plain Annealed Copper Class 5

  • Insulation

    Rubber

  • Sheath

    Rubber

  • Min Operating Temperature

    -30°C

  • Max Operating Temperature

    90°C

  • Core Colours

    Red,Black

  • Sheath Colours

    Red,Black

  • Current Carrying Capacity

    For current ratings refer to IEC

The Characteristics of Welding Cable

zw cable is a professional welding cable manufacturer in China. We can supply a competitive welding cable prices. Our unrivaled range of electrical cables include rubber welding cable, empdm welding cable, and pvc welding cable. Most of types we have in stock. All of our cables are manufactured to IEC Standards.Over the past years, we have established long-term friendly and cooperative relations with many enterprises abroad. If you are also looking for welding cable prices such as welding cable 70mm price, zw cable will be your best choice. Please leave your message, we will send our welding cable prices list to you in 12 hours.
Standard:
Welding Cable Prices
Extra Flexibility:
When high flexibility required, welding cable shall make a substitute.
Feature:
Resistant to cuts, tears and abrasion in addition to moisture. Welding Wire offers good color retention along with great flexibility.
Suitable Uses:
Welding Cable is used for connection from electrode holder and clamp to arc welder, bus, welding box or transformer. May also be used in automotive applications where high flexibility and superior abrasion and chemical resistance is required.

Welding Cable Prices Parameter

Conductor Size Stranding(0.25mm)225 Conductor Diameter(in.) Insulation Thickness(in.) Total Diameter(in.) Max Amp
6 AWG 253 0.20 0.06 0.32 115
4 AWG 370 0.23 0.06 0.35 150
2 AWG 634 0.30 0.06 0.42 205
1/0 1004 0.47 0.08 0.53 285
2/0 1255 0.43 0.08 0.59 325
4/0 2047 0.56 0.08 0.72 440
